HT-6510E Shore Hardness Tester with average calculate function
Model HT-6510E is suitable for soft materials such as Foam and Sponge.
* It meets standards of DIN 53505, ISO 868, ISO 7619, ASTMD 2240, JISK7215.
* With average calculate function. * Peak value deposit function. * Under-voltage alarm function. * Use “USB data output” and “RS-232 data output” to connect with PC. * Provide “Bluetooth ™ data output” choice. Model Informations:
|Model||Indenter||Tested Materials||Hardness Value|
|A||0.79 Truncated (Frustum) Cone||Soft Rubber, Elastomers, Natural Rubber Products, Neoprene, Resin, Polyester, Soft PVC,Lleather, etc.||20 ~ 90 A|
|B||R 0.1 Cone||Middle Hard Rubber Materials, Typewriter Rollers, etc.||Above 90 A, Below 20 D|
|C||0.79 Truncated (Frustum) Cone||Plastics and Middle Hard Rubber Materials||Above 90 B, Below 20 D|
|D||R 0.1 Cone||Fibre Plastics, Hard Rubber, Hard Plastic Materials, Plexiglas,Stiff Thermo Plastics, Formica, Print Roller, Vinyl-plate, Cellulose Acetate, etc.||Above 90 A|
|DO||R 1.2 Spherical Radius||Plastics and Middle Hard up to Hard Rubber Materials||Above 90 C, Below 20 D|
|O||R 1.2 Spherical Radius||Soft Elastic Materials, Print Rollers, Middle Firm Textile Fabrics, Nylon, Orlon, Perlon, Rayon||Below 20 DO|
|OO||R 1.2 Spherical Radius||Sponge- and Cellular Rubber, Foam Rubber, Silicone, Gel-like Materials||Below 20 O|
|E||R 2.5 Spherical Radius||Hard Sponge, EVA||Above 90 DO, Below 20 D|
|Parameters Displayed||Hardness Result, Average Value, Max. Value|
|Measurement Range||10~90 HE|
|Measurement Deviation||<1 H|
|Auto Switch Off|
|Battery Indicator||Low Battery Indicator|
|Operating Conditions||Temperature: 0 ~ 40 C Humidity: 10 ~ 90 %RH|
|Power Supply||4 x 1.5 V AAA Size (UM-4) Battery|
|Dimensions||162 x 65 x 28 mm|
|Weight||170 g (Not Including Batteries)|
1. Main Unit
2. Carrying Case
3. Operation Manual
4. Pin Length Test Block
1. Shore Hardness Tester Measurement Stand
2. Rubber Hardness Test Block (A / D Type )
3. USB, RS-232C data cable with software
4. Bluetooth data out put with software
