PROVA-210 solar Module Analyzer with calculation of efficiency
Product description Features 60V, 6A (PROVA 200A) 60V, 12A (PROVA 210) 85V,8.5A (PROVA 218) I-V Curve Test for Solar Cell Max. Voltage (Vmaxp) and Max. Current (Imaxp) at Max. Power (Pmax) I-V Curve with cursor Calculation of Efficiency (%) Specifications: Electrical Specifications (23°C±5°C, Four-wire Measurement) DC Voltage Measurement: PROVA 200A (60V, 6A) PROVA 210 (60V, 12A) Product specification 0- 10V 0.001V ±1% ± (1% of Vopen ± 0.1V) 10–60V 0.01V ±1% ± (1% of Vopen ± 0.1V) DC Current Measurement Range (60V / 6A) Resolution Accuracy 0.01 – 10A 1mA ±1% ± (1% of Ishort ± 9mA) 10–12A 1mA ±1% ± (1% of Ishort ± 9mA) DC Current Simulation Range (60V / 6A) Resolution Accuracy 0.01–10A 1mA ±1% ± 9mA 6-10A 1mA ±1% ± 0.09A General Specifications Battery Type: Rechargeable, 3400mAh Li-ion Battery Linear Scan 400times (60V-0V, 0A-12A) AC Adaptor: AC 110V or 220V input, DC 15V/ 1 ~ 3A output Dimension: 257 (L) x 155 (W) x 57 (H) mm 10.1 (L) x 6.1 (W) x 2.2 (H) in Weight: 1160 g / 40.0 oz (battery included) Accessories: Users manual x 1, AC adaptor x 1 RS232C (to USB Bridge) Cable x 1 Rechargeable batteries x 8 Software CD x 1 Kelvin Clips (6A max) x 1 set
